AWS A5.11 / ASME SFA5.11 ENiCrFe-2

JIS Z3224 DNiCrFe-2

EN ISO 14172 Ni 6092

Applications

AWS A5.11 / ASME SFA5.11 ENiCrFe-2 is designed for welding of Inconel 600 and 601, Incoloy 800 and 800HT dissmillar welding of stainless steels and low-alloyed steel & Nickel-alloyed steel.(Inconel, Incoloy, Monel alloys) It can be used for welding of overlay cladding where a similar composition.

Characteristics on Usage

Notes on Usage

Welding Position(All-Position)                  Current

it has High impact toughness at low temperature -196℃(-321℉), excellent arc & slag
stability and hot cracking resistance. It provides Better productivity(anti-heat feature).

① Remove rust, Scales, Oil, Paint, Slag of tack welds.
② Keep the arc as short as possible.
③ Dry the electrode at 300~350℃(572~662℉) for 60 minutes before use.
④ Keep the welding current as low as possible.

AC or DC +
